Product description
YT-98H-D/YT-98H-D-A series is a fixed single &multi gas detector. It is able detect 1-6 kinds of gases simultaneously and continuously. With IECEx, ATEX certified and non-contact magnetic wand design, it can be installed and operated in hazardous areas. It supports 3-wire 4-20mA, RS485 Modbus, relay and optional Hart signal output, making it compatible with most control systems. With optional wireless data transmission so user can view real time data on lap top,mobile phone remotely.
Product advantage
- Up to 6 kinds ofgases can be detected simultaneously.In complex and multi-gas environments, it is able to saving installation time and effort
- With wireless communicate function, uploading data to cloud platform so user is able to check and download data remotely.There is also SMSand E-mail alarm alert function in real time.(optional)
- With manually span and zero calibration function,making gas monitoring more accurate and more reliable.
- Standard 4-20mA analog signal, RS485 modbus signal and relay signal output, optional HART output.
- Standard infrared remote control,optional non-contact magnetic wand control.
- With sound and light alarm function, there is sound and light alarm when reaching the alarm point.(optional)
- With fault alarm, will send alarm when sensor disconnect.
- IP66 protection grade, water proof and dust proof
company profile
In 2010, Shenzhen Yuante Technology Co., Limited came into existence. During the past 16 years, it has specialized in the design, production, and sales of high-quality gas detection equipment and systems. Gas detectors serve as the company's core products, and it provides customized production lines and solutions for industries like Oil, Chemical, Medicine, and Energy. Following around 10 years of vigorous development, Yuante has established itself as an important supplier. The company adheres unwaveringly to management ideas of market orientation, innovation impetus, quality for survival, and development for growth. Its corporate culture embodies friendliness, openness, and strictness. Thanks to standardized management, it has gathered a group of outstanding talents and formed a capable management and R & D team. The employees cooperate harmoniously in product R & D, production, and maintenance, and have a deep understanding of the customer-first concept and a strong service ethic, thus gaining the trust and support of customers. The essential element of a detector is its accuracy and swift response. Relying on years of measurement experience and unique solutions, through independent R & D, collaborative work, and learning from the latest overseas technologies, Yuante's products have excelled over domestic brands and are competitive in the global market. The company is always exploring methods for development and advancement to meet the varied demands of its customers.
certifications
FAQ
specification
| Sampling method | Built in pump |
| Pump flow rate | 0.35-0.5 L/Min |
| Gas detected | Ozone(O3),VOC, Oxygen(O2), Combustible gases(EX/LEL), Carbon monoxide(CO), Hydrogen sulfide(H2S), according to customer's
requirements |
| Measure Range | Specified according to application |
| Resolution | O3: 0.01ppm, 0.1ppm
VOC: 0.001ppm, 0.01ppm, 0.1ppm, 1ppm
O2: 0.01%VOL
EX: 1%LEL/0.01%VOL
CO: 0.1ppm/1PPM/1ppm
H2S: 0.01ppm/0.1PPM Specified according to application and sensor type |
| Response time(T90): | ≤10 seconds |
| Signal output | 4-20mA, RS485, 1 set of relay output; 1-5VDC(optional), 2 sets of relay output(optional) |
| Display: | High-light nixie tube display |
| Zero shift | ≤±1%(FS/year) |
| Connection mode | G1/2 external thread explosion-proof flexible pipe |
| Operating time | 24H |
| Size | 286*202*96mm (H x W x D) |
| Weight | 3.4kg (3.8kg with alarm light) |
| Protection grade: | IP65 |
